Hilti PMD 200

  • Prize
    Winner in Project Management - Drawing, 3 D, site layout, Floor plan, and Architectural software
  • Company/Firm
    Hilti Corporation
  • Lead Designer
    Hilti Corporation
  • Project Date
    2020
  • Project Link

PMD 200 is a compact, laser-based tool used to transfer locations from an architect’s drawings to reality on the construction site. Unlike traditional tools, this device removes many manual measuring tasks required to mark the exact location of internal walls. All tasks are controlled intuitively via a dedicated tablet. This speeds up the process and removes scope for error. In addition, it makes complicated geometry, such as curved walls, more accurate and thus ambitious projects easier to implement.

Intuitive 2D layout laser tool to easily mark out drywall track locations and complex geometries in indoor environments
Accuracy: ±0.12 in at 82 ft
Max. operating distance (diameter): 164 ft (lines)
Maximum operating time: 8 h
